Polyester Battens

Lightweight Polyester batten system for walls and ceilings offering very high acoustic performance.

enquirerequest samples
Fire Rating
Group 1S New Zealand
Group 1 Australia
Sustainability
Manufactured from 60% recycled PET
Key FeaturesColour Optionsproduct detailsinstallationprojects

Key Features

  • Suitable for direct fix and suspended ceiling systems
  • 5 year product warranty
  • Group 1S fire rating - New Zealand
  • Group 1 fire rating - Australia
  • Customisable batten spacings and batten sizes
  • Very high NRC ratings are achievable - up to 0.95 NRC
  • Extremely lightweight

Polyester Colours

Product Details

Environment

Featurecraft polyester is manufactured from 60% recycled fibres and 40% virgin fibres.

Timber Species

Featurecraft Polyester battens come in a wide range of colours to suit any interior

Size & Rebates

​Ask about custom sizes and shapes for larger projects.

Fittings

The male aluminum profile (ZBI) is extruded in the back of the batten and the female profile (ZBC) is screw fixed onto the horizontal panel frame (ZPF).

Application

Feature Battens Clip System

Exploded View (For Smaller Battens)
Application

Feature Battens Clip System

Exploded View (For Larger Battens)
Acoustic Backing & Sound Installation

Acoustic backing panels can be 12mm (0.40 NRC) and 25mm (0.60 NRC) and are incorporated into the system for great NRC performance. They also reduce costs as they can replace the need for alternative wall & ceiling lining.

The acoustic panels have a Group 1 (Aus) and Group 1S (NZ)  fire rating and are available in the range of colours shown.

Alternatively, acoustic blanket is recommended for achieving up to 0.95 NRC

Polyester Colours

Wall Batten Installation

Panel Frame fix - straight wall (acoustic integration)

The Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centres then the 12mm acoustic backing is slid into place between the panel frames. The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.

Click here to view  PDF version  of the section views showing the ZPF panel frames' dimensions.

Application

Polyester Feature Battens Install Procedure

Walls
Panel Frame fix - curved wall

The curve-able Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centres then the 12mm acoustic backing is slid into place between the panel frames. The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.

The Rondo components are Flexible Track 103 (51mm), 107 (64mm), 108 (76mm) and 109 (92mm) and steel studs to suit.

Application

Polyester Feature Battens Install Procedure

Curved Walls/Ceilings
Direct fix straight wall (non-acoustic )

The Featurecraft batten connector is screw fixed through the existing lining into timber or steel studs at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.

Application

Polyester Feature Battens Install Procedure

Direct Fix Wall
Application

Polyester Feature Battens Install Procedure

Exploded View (for smaller battens)
Application

Polyester Feature Battens Install Procedure

Exploded View (for larger battens)

Ceiling Batten Installation

​Panel Frame fix - straight ceiling (acoustic integration)

The Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centers. The 12mm acoustic backing is slid into place between the panel frames.

The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place.

A very quick and simple installation.

Application

Polyester Feature Battens Install Procedure

Direct Fix Ceilings
Direct fix straight ceiling (non-acoustic)

The Featurecraft batten connector is screw fixed onto the Gib or framing at the desired spacing, followed by the Featurecraft batten infill screw fixed into the back of the rebated feature batten. Then the batten - infill first - is simply clicked into place onto the batten connector

A very quick and simple installation.

Application

Polyester Feature Battens Install Procedure

Direct Fix Ceilings / Soffits
Integration with the Rondo Keylock suspended ceiling system

The curve-able Featurecraft batten frame is horizontally fixed onto the Rondo Keylock joiner 139, then the 12mm acoustic backing is slid into place between the batten frames. The Featurecraft batten connector is then screw fixed onto the batten frame at the desired spacing followed by the Featurecraft batten infill screw fixed into the back of the rebated feature batten. The batten is simply clicked into place. A very quick and simple installation.

The Rondo components are Flexible Track 103 (51mm), 107 (64mm), 108 (76mm) and 109 (92mm) and steel studs to suit.

Application

Polyester Feature Battens Install Procedure

Suspended Ceilings
Application

Feature Battens Install Procedure

Suspended Ceilings
Application

Fix ZBC batten connecter directly to Rondo Furring Channel 129

Application

Rondo integration (non-acoustic)

Fix batten connecter direct to Gib.
Application

"Lift-up" Access Panel Option

Application

Hinged Access Panel Options
