Durable and non-corrosive batten system with acoustic backing options for walls and ceilings for interior & exterior applications.
Profiles manufactured from recycled aluminium.
19 different woodgrain powder-coating finishes that match our solid timber and MDF / Timber Veneer batten range
Anodizing options available
Powder-coating options available
Other coatings may also be available on request.
Ask about custom sizes and shapes for larger projects.
-min.png)
The male aluminum profile (ZBI) is extruded in the back of the batten and the female profile (ZBC) is screw fixed onto the horizontal panel frame (ZPF).
Acoustic backing panels can be 12mm (0.40 NRC) and 25mm (0.60 NRC) and are incorporated into the system for great NRC performance. They also reduce costs as they can replace the need for alternative wall & ceiling lining.
The acoustic panels have a Group 1 (Aus) and Group 1S (NZ) fire rating and are available in the range of colours shown.
Alternatively, acoustic blanket is recommended for achieving up to 0.95 NRC
The Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centres then the 12mm acoustic backing is slid into place between the panel frames. The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.
Click here to view PDF version of the section views showing the ZPF panel frames' dimensions.
The curve-able Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centres then the 12mm acoustic backing is slid into place between the panel frames. The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.
The Rondo components are Flexible Track 103 (51mm), 107 (64mm), 108 (76mm) and 109 (92mm) and steel studs to suit.
The Featurecraft batten connector is screw fixed through the existing lining into timber or steel studs at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place. A very quick and simple installation.
The Featurecraft panel frame is horizontally screw fixed onto timber or steel framing at 450mm to 600mm centers. The 12mm acoustic backing is slid into place between the panel frames.
The Featurecraft batten connector is then screw fixed onto the panel frame at the desired spacing and the Featurecraft batten infill is screw fixed into the back of the rebated feature batten and simply clicked into place.
A very quick and simple installation.
The Featurecraft batten connector is screw fixed onto the Gib or framing at the desired spacing, followed by the Featurecraft batten infill screw fixed into the back of the rebated feature batten. Then the batten - infill first - is simply clicked into place onto the batten connector
A very quick and simple installation.
The curve-able Featurecraft batten frame is horizontally fixed onto the Rondo Keylock joiner 139, then the 12mm acoustic backing is slid into place between the batten frames. The Featurecraft batten connector is then screw fixed onto the batten frame at the desired spacing followed by the Featurecraft batten infill screw fixed into the back of the rebated feature batten. The batten is simply clicked into place. A very quick and simple installation.
The Rondo components are Flexible Track 103 (51mm), 107 (64mm), 108 (76mm) and 109 (92mm) and steel studs to suit.
